Kollmorg system laser guided stacker Linde forklift AGV

Basic information
Navigation: laser
AGV type: forklift AGV
Payload: 800kg, 1200kg, 1500kg, 1800kg
AGV size: big
Material type: pallet

Contact
  • Description
  • Specification
  • Image
  • Case
  • Video
  • Download
AGV Introduction
Kollmorgen system laser guided stacker Linde forklift AGV is a popular model to transfer pallets and lift pallets automatically. Scanner on top of the forklift AGV sends out signals and receives signals from the laser reflectors fixed on the wall, which helps the AGV to navigate at 5mm accuracy, very reliable and low maintenance rate.
The AGV consists of the vehicle body part, vehicle controller, moving& turning unit, laser orientation scanner, laser safety protection device, sensor etc.  Laser scanner and protection device adopted synchronized localization technique, the laser scanner detect the area terrain, and depicting a map in its internal IPC, thus the AGV moving trace and position can be located, reducing moving route, increasing work efficiency.

Company info
Business type: manufacturer
Main products: auto guided vehicle, automated guided cart, automatic guided, autonomous mobile robot, AMR, agv vehicle, agv material handling, MIR
Number of employee: 120
Location: Shenzhen Guangdong, China
Year of establishment: 2013

Applications
production lines, warehouse

Packing info
In wooden boxes on pallets.
Product details
Product Kollmorg system laser guided stacker Linde forklift AGV
Payload Pallet
Control Mode PLC
Size customized
Navigation laser navigation
Direction of Moving Forward, backward, right and left turning
Communication Wireless LAN (Optional)
Lift 1m, 2m, 3m, 4m, 5m, 6m
Load 1000kg, 2000kg, 3000kg,  depends
Speed of Moving 0-50 M/MIN
Guidance Accuracy ±5mm
Stop Accuracy ±5mm
Turning Radius depends
Driving Mode Steering wheel drive
Power Supply of Driving DC48V
Battery Lead battery/ Li battery
Charging Mode Manual Charging / Automatic Charging
Battery lifespan Discharging Times: >1500 Times
Safety sensor range Angle 0-180°, distant 0-3m adjustable
Safety Protection Obstacle safety sensor+ bumper
